Especificações Técnicas:
EAN 7898722600874
CPU Supports 8/9rd Gen (lvy Bridge). Intel® Core™ CPUs (LGA1151)
Chipset Intel H310 ® Express Chipset
Memory 2*288-pin DDR4 SDRAM slots
Memory up to 32GB
Supports dual channel DDR4 2666/2400/2133MHz
I/O Interface 1 x PS/2 keyboard port, 1 x PS/2 mouse port
1 x VGA port
1 x HDMI port
1 x DVI port
1 x RJ45 port
1 x 3-in-1 Audio port(line In/Line Out/MIC IN)
Onboard Interface 1 x 24-pin ATX power connector
1 x 8-pin ATX 12V power connector
1 x USB2.0 connector, can support 2*USB 2.0
1 x USB3.0 connector, can support 2*USB 3.0
1 x F_AUDIO connector
1 x F_PANEL connector
1 x SPEAKER connector
2 x FAN connector
4 x serial SATA/6GB/S connector port
1 x LPC_DEBUG connector
Integrated sound with 6-channel HD Audio Codec onboard
provides front audio interface;
provides front stereo mic interface;
Integrated Lan 1 x GigaLAN 10/100/1000 Mbps
Expansion Slot 1 x PCI Express x16 slot
1 x PCI Express x1 slot
1 x NVMe M.2 connecto
